STANDARD : DIN 933,ISO 4017, DIN 961, ISO 8676, DIN558SIZE : M3 - M52 LENGTH 6 - 200MMMATERIAL : CARBON STEEL, STAINLESS STEEL, BRASSGRADE : 4.8 5.8 6.8 8 10.9 12.9 A2-50 A2-70 A4-70 A4-80FINISH : SELF COLOUR ,ZINC PLATED, HDG,ZINC FLAKEPACKAGING : BULK PACK | SMALL BOXEDHEAD STYLE : HEXAGONALCONNECTION : COMMON BOLTODM/OEM : AVAILABLE
STANDARD : DIN985SIZE : M3 - M48MATERIAL : Carbon Steel,Stainless SteelGRADE : 6, 8, 10 (Carbon Steel) A2-50, A2-70,A4-70,A4-80（Stainless Steel）FINISH : Plain | BZP | Mechanical Galvanized| GEOMET ...PACKAGING : Bulk Pack| Small Boxed or CustomizedAPPLICATION : Machinery, Chemical Industry, BuildingHEAD STYLE : Hexagonal
STANDARD : DIN 934SIZE : M2.5 - M100MATERIAL : STEEL GRADE 8, 10, 12GRADE : 6, 8, 10, 12, A2, A4, BRASSFINISH : PLAIN | BZP | HDG | GEOMET ...PACKAGING : BULK PACK | SMALL BOXED
STANDARD : DIN 963
SIZE : M1.6 TO M10,LENGTH 4 - 100MM
MATERIAL : CARBON STEEL
GRADE : 4.8
FINISH : ZINC PLATED
PACKAGING : BULK PACK | SMALL BOXED
• Conforms to DIN 963
•Countersunk head gives a flush finish once in place
•Designed to join component parts together, and are fitted to a pre-drilled and tapped hole or nut.
• Example applications include machinery, engines, manufacturing, industrial equipment, maintenance and repair.
|
d1 |
M3 |
M3.5 |
M4 |
M5 |
M6 |
M8 |
M10 |
M12 |
|
d2 |
5.6 |
6.5 |
7.5 |
9.2 |
11 |
14.5 |
18 |
22 |
|
k max. |
1.65 |
1.93 |
2.2 |
2.5 |
3 |
4 |
5 |
6 |
|
n |
0.8 |
0.8 |
1 |
1.2 |
1.6 |
2 |
2.5 |
3 |
|
t min. |
0.6 |
0.7 |
0.8 |
1 |
1.2 |
1.6 |
2 |
2.4 |
